FreeStyle T44/T24 LED
Kino Flo® Lighting Systems’ True Match® FreeStyle LED tubes are specially designed for operation in FreeStyle T44 & T24 fixtures for film production or stage design lighting. The FreeStyle LED tubes display Kino Flo’s True Match white light and RGBWW color management system found in Kino Flo’s LED lighting fixtures.
FIXTURE FEATURES
The tubes are 4ft (1.2m) & 2ft (0.6m). On camera, FreeStyle LED tubes photograph with the same softness, the same subtle color reproduction as Kino Flo’s award-winning T12 high-output lamps. In addition to high color rendering, cinematographers will see the difference the 310° LED tube makes when operated in a fixture or out of the fixture as a remote “sabre” of light. Paired with the FreeStyle fixture and light intensifying reflector, the tube projects soft light forward at a 100° beam angle at about the same light levels you’d get from a 1000W tungsten softlight.
The FreeStyle T44/T24 LED System (SYS-FT44U/SYS-FT24U) consists of:
FreeStyle T44/T24 LED Fixture plus 4 x FS-48 LED Tubes or 4 x FS-24 LED Tubes, Mounting Plate, FreeStyle 140X LED DMX Controller, and Extension Cable.
It was designed in this manner to allow the greatest flexibility in lighting solutions for challenging situations.
FreeStyle T44/T24 LED Features
- Color Rendering TLCI >96, CRI >96, TM-30-18 Rf=95, Rg=103
- Kelvin presets
- Dial-in color temperature control between 2500K-9900K
- Green/Magenta Control
- Hue angle and Saturation adjustments
- Kino Flo presets and Gels
- RGB control
- CIE xy
- FX Control
- Camera Profiles LUTs
- Color Space
- Works with Apps with predetermined RGB presets or color wheels
- Can use preset buttons to store custom Kelvin settings
- Light levels do not change when selecting Kelvin settings
- No color shift while dimming
- Universal input 100VAC-240VAC or 24VDC
- Energy efficient, draws 1.25A, 120VAC and 6.25A, 24VDC
- Flicker-free, quiet operation
- Full range onboard and DMX dimming
- DMX wireless link (Lumen Radio®)
- DMX Auto Terminate
- The firmware is updatable from a PC using the Mini B USB data Port
- T44 Dims: 52 x 3.5 x 13” w/ 6.5” brndr (132 x 9 x 33cm w 16.5cm brndr)
- Weight w/ Tubes: 12.5 lb (6kg)
- T24 Dims: 28 x 3.5 x 13” w/ 6.5” brndr (71 x 9 x 33cm w/ 16.5cm brndr)
- Weight w/ Tubes: 8 lb (4kg)
FreeStyle T44/T24 LED Design
- Remote fixture with built-in barndoors
- Fixture includes removable 90° Honeycomb Louver
- KinoGrip Center Mount
- Lightweight, slim profile
- Mounts to stand, light enough to be hand-held
- FreeStyle Tubes
FreeStyle T44/T24 LED Modular Design
The FreeStyle T44/T24 Fixture houses the tubes and is comprised of built-in barndoors, a Louver, Reflector and Tube Harness. The Louver and Reflector are held in place with Velcro fasteners.
There is a strain relief on the tube Harness to ensure the connectors don’t pull off the tubes during operation. To get the harness away from the fixture, turn the 1/4 turn fastener and rotate counter-clockwise to release.
ACCESSORIES
System
System Components
CFX-F484
CFX-F244
FS-48
FS-24
MTP-KG41
X12-F425
LED-140X-120U
LED-140X-230U
Fixture Components
FIX-F484
FIX-F244
HAR-FS4
LVR-K490-P
LVR-K290-P
REF-F484
REF-F244
System – Tube Only
SYS-FTS4004
SYS-FTS2004
System – Tube Only Components
FS-48
FS-24
MTP-F101
X08-F125
X12-A4
LED-140X-120U
LED-140X-230U
FreeStyle Tubes/Mounting
FS-48
FS-24
MTP-F100
MTP-F101
MTP-F102
MTP-F103
MTP-F103W
MTP-F105
MTP-F200
MTP-F201
Accessories
SYS-BK12
DFS-4804
DFS-4804-H
DFS-SL20
DFS-SL20-H
REF-F481
REF-F241
X08-F125
X12-A4
Mounting/Stands/Cases
MTP-BG41
MTP-BG41S
MTP-KG41
MTP-BW41
MTP-BW41S
MTP-KW41
MTP-BAL1
MTP-901
MTP-902
MTP-903
MTP-BRA
STD-M30
STD-M36
STD-D1
KAS-FT44C
KAS-FT24C
KAS-FT44G
KAS-FT24N
BAG-STD
BAG-401
BAG-SL20
