    LiteCard Chroma Series, Cine-Five, RGB+HY,24V

    LiteCard Cine-Five features cinema-quality 95+ CRI hybrid with the ability to add in crisp RGB color accents. This LiteCard variation is 24 volts.

    Request InfoWhere To Buy

    SPECIFICATIONS

    • Power: 100W (total potential power per card)
    • Input Voltage: 24 VDC nominal (20-25.5 VDC constant voltage)
    • Current: 4.17A (total potential current per card)
    • CCT: Hybrid 2600K (+/-300K) & 6000K (+/-300K)
    • CRI: 95+ (Tungsten), 95+ (Daylite)
    • TLCI: 95.8 (Tungsten), 98.1 (Daylite)
    • Beam Angle: 120°
    • Lumens (lm) Whites: 1639.9 (Tungsten), 1726.6 (Daylite)
    • Lumens (lm) Colors: 664.9 (Red), 1456.9 (Green), 345.1 (Blue)
    • Color Space Compliant: Yes (with appropriate controller)
    • Green/Magenta: : Yes (with appropriate controller)
    • Weight: 0.428 lbs. (0.19 kg) including wire lead
    • PCB Dimensions: 240mm (9.45 in.) x 480mm (18.90 in.)
    • Card Overall Thickness: 2.2mm (0.087 in.)
    • Segment Dimensions: 60mm (2.36 in.) x 80mm (3.14 in.)
    • Segments per Card: 24
    • Total LED Quantity: 288
    • LEDs per Cut Segment: 12
    • LED Spacing: 20mm (.79 in.)
    • Dimming Range: 0-100%
    • Operating Temperature: -10°C to +50°C (14°F to +122°F)
    • Connector: Bare Wire
    • Mounting: Adhesive backing
    • LED Lifetime: 50,000 Hrs
    • IP Rating: 20
    • Certifications: UL Listed (Canada/US), CE Compliant (Europe)

    Downloads

    https://litegear.ddev.site/wp-content/uploads/2019/11/LiteCard-Chroma-Cine-Five-Data-Sheet.pdf
    PDF, 1 MB
    		DOWNLOAD
    LiteCard Chroma Cine-Five Data Sheet
    PDF, 1 MB
    		DOWNLOAD

    Additional information

    Weight .2 lbs
    Dimensions 10.5 × 21 × .25 in
